Čerpadlo FW2 4030 S Nickel Comet
Hydroflex · kód 6410 0127
Cenníková cena (DPC)
530,59 €
431,37 € bez DPH · DPH 23 %
U dodávateľa skladom
Máte záujem? Ozvite sa nám.
+421 37/657 88 21 · steps@steps.sk
+421 37/657 88 21 · steps@steps.sk
Mám záujem – nezáväzný dopyt
Technické údaje
| Vstup | 1/2" F |
| Prietok | 15.2 l/min |
| Tlak | 207 bar |
| Shaft diameter | 24 mm |
| Výstup | 3/8" F |
| Výkon | 5.9 kW |
| Výkon | 7.9 HP |
| Teplota | 85 °C |
Popis
FW2 Nickel
Hot Water Pump (max 85°C – 185°F)
Nickel Plated Head
Special compound seals
Reversible Crankcase for Right or left Hand Mounting
Hardened Stainless Steel piston Guides Highly Efficient Stainless Steel Check Valves
Solid Ceramic Plungers
High & Low Pressure Seals: High Quality Buna-Textile Packings
Additional Anti-Extrusion Ring under the Seal
Solid Brass Manifolds
Special Forged Brass Oversized Connecting Rods
Die-Cast, Anodized Aluminum Crankcase
Highly Quality Tapered Roller Bearings
Optimal Oil Bath for High Speed Operation
S 24mm Solid Shaft for Belt Drive, Gearbox or Flex Couplers
