Čerpadlo RW 9515 S Comet
Hydroflex · kód 6517 2100
+421 37/657 88 21 · steps@steps.sk
Mám záujem – nezáväzný dopyt
Technické údaje
| Vstup | 1/2" F |
| Výkon | 11.9 HP |
| Tlak | 124 bar |
| Vstup | 3/4" F |
| Výstup | 3/8" F |
| Prietok | 36.9 l/min |
| Výkon | 8.9 kW |
Popis
RW
Brass Head
Crankcase: Die-Cast Aluminum Alloy for Protection Against Corrosion
Piston Guides are Heat Treated Stainless Steel
Highly Efficient Stainless Steel Check Valves
Solid Ceramic Plungers
Brass Manifold: Forged for Maximum Strenght and Longer Life up to 310 bar
One Piece, Solid Bronze Alloy Connection Rods
High Quality Tapered Roller Bearings
Large Oil Capacity Dissipates Heat and Improves lubrication for Longer Life
Exclusive No-Oil-Leak System in the crankcase minimising wear of the piston oil seal (Patented)
Exclusive Sealing System Between Crankcase And Pump Head that prevents dust and dirt getting inside where the pistons work but letting water out (Patented)
Solid Shaft 24mm for Belt Drive, Gearbox or Flex Couplers
